Pixel Configuration:SMD1921
Pixel Pitch (mm):3.9
Pixel matrix per panel:128X128
Request DemoEasy to Operate
High Gray Grade
Handiness
High Stability
Power box modular design can be quickly plugged.
More models for your more needs, please choose your favorite one...
Product Name | R2.6 PRO | R2.9 PRO | R2.9T PRO | R3.9 PRO | R3.9T PRO | R4.8T PRO |
Pixel Configuration | SMD1515 | SMD2121 | SMD1516 | SMD2121 | SMD1921 | SMD1921 |
Pixel Pitch(mm) | 2.6 | 2.9 | 2.9 | 3.9 | 3.9 | 4.8 |
Pixel matrix per panel | 192x192 | 168x168 | 168x168 | 128x128 | 128x128 | 104x104 |
Cabinet Dimensions(mm) | 500x500x84 | 500x500x84 | 500x500x84 | 500x500x84 | 500x500x84 | 500x500x84 |
Transparency Rate | \ | \ | \ | \ | \ | \ |
Refresh Rate(Hz) | 3840 | 3840 | 3840 | 3840 | 3840 | 3840 |
Drive Mode | 1/32 | 1/28 | 1/28 | 1/16 | 1/16 | 1/13 |
Brightness (nits) | 800-1000 | 800-1000 | 4000-4500 | 800-1000 | 4000-4500 | 4000-4500 |
Horizontal / Vertical Viewing Angle | 140/140 | 140/140 | 140/140 | 140/140 | 140/140 | 140/140 |
AC Input Power Maximum/Average | 530/180 | 530/180 | 530/180 | 530/180 | 530/180 | 530/180 |
Contact our sales team today to discover how our energy-efficient, high-brightness, and stable indoor LED screens can transform your space.
